HD-CR 35 NDT Image plate scanner - Each
NDT equipment, repair and calibration.

HD-CR 35 NDT Image plate scanner

Each TreFoc technology BSR upto 40 um

HD-CR 35 NDT Image plate scanner
HD-CR 35 NDT Image plate scanner
HD-CR 35 NDT Image plate scanner
HD-CR 35 NDT Image plate scanner
HD-CR 35 NDT Image plate scanner
Price on request *Prices are exclusive of VAT
Article code55901
Technical data
Resolution
12.5 – 200 µm continuously adjustable (TreFoc Technology)
BSR (Basic Spatial Res.)
30 µm certified by BAM
Grey level resolution
16 bit, 65.536 grey levels
Dimensions (H x W x D)
40 x 37 x 47 cm
15.8" x 14.6" x 18.5"
Weight
17,5 kg
38.6 lbs
Electrical
100 – 240 VAC / 50 – 60 Hz, < 140 W
Temperature range
10 to 35 °C
50 to 95 °F
Noise Level
< 39 dB(A)
Laser Class
I (EN 60825-1: 1994-03 + A1: 2002-07 + A2: 2001-03) + CFR 1040.10
PC-Connection
Ethernet (TCP-IP protocol), W-LAN
Display
4.3“ TFT, 800 x 480 px
Storage
SDHC, max 32 GB
Software
DÜRR NDT D-Tect
